HUAWEI ME909u-521 Carte LTE 4G
HUAWEI ME909u-521- Carte LTE 4G pour Firewall E-WALL AP33x sous logiciel pfSense®
Carte livré sans abonnement.
- Form Factor: Module: PCIe Mini Card
- Technology: 4G LTE Cat 3 w/ 3G Fallback
- Frequency: LTE Band 1/2/3/5/7/8/20 , HSPA+ 850/900/1900/2100 GPRS/GSM
- Carrier: Multiple Carriers
- Features: w/ GPS
- The ME909U-521 is a LTE module for EU with mini-PCIe interface, supports LTE (FDD) B1/B2/B3/B5/B7/B8/B20, Penta-band DC-HSPA+/HSPA/WCDMA, for European network coverage.
- It has low power consumption, support for Global Navigation Satellite System (GNSS, GLONASS) and European carrier certifications.
Détails du produit
Fiche technique
- Facteur de forme
- mPCIe Full size
- Constructeur
- HUAWEI
- MIMO (Multiple-Input Multiple-Output)
- Oui
- Bande LTE
- B1 (2100)
B2 (1900)
B3 (1800)
B5 (850)
B7 (2600)
B8 (900)
B20 (800DD) - Région LTE
- Asie
Europe - Bandes UMTS
- B1 (2100)
B2 (1900)
B8 (900)
B26 (850) - Technologie
- LTE - cat 3
- Interface Antenne
- IPEX MHF/U.FL
- GPS
- Oui
- Max Download Speed
- 100 Mbps
- Max Upload Speed
- 50 Mbps
