Firewall Appliance AP234 under OPNsense 3 ports 4GB SSD 500GB
    E-WALL

    Firewall Appliance AP234 under OPNsense 3 ports 4GB SSD 500GB

    Reference: AP234500O
    €370.00
    Delivered within 24/48h

    Appliance Firewall AP234 3 ports, installed under OPNsense®
    Pre-installed under OPNsense® 23.x included, Firewall ready to use.
    GX-412TC quad core processor / 4GB RAM
     / 3 Intel GigE / SSD 500GB
    2 miniPCI express / 1 mSATA - SATA / SSD disk support and WIFI card support
    3 customizable Gigabit ports (WAN / LAN / DMZ)
    AES-NI support for accelerating VPN encryption
    Low consumption fanless box (10W), no noise - Small footprint
    EU / UK format power supply - 1-Year workshop warranty

    Quantity
      In stock

    Product Details

    Data sheet

    Model
    AP2x
    Operating system
    OPNsense®
    CPU type
    AMD GX-412TC
    Number of Cores / Threads
    4C / 4T
    CPU frequency
    1 GHz - Burst 1.4 Ghz
    Memory capacity
    4GB
    Memory type
    DDR3
    Number of memory slots
    0 Slot
    Maximum memory capacity
    4GB
    Hardware Encryption Engine (AES-NI)
    Oui
    Number of disk bays
    1
    M.2 drive slot
    No
    Compatible disc type
    miniPCIe mSATA
    Hotswap disk
    No
    Installed disk capacity
    512GB
    PCIe Expansion
    2 x miniPCI express (one with SIM socket)
    Number of USB Ports
    2 x USB 3.0
    Number of network ports
    3 x 1GbE (RJ45)
    Ethernet Chipset
    Intel i210AT
    WIFI / LTE card
    None
    SIM slot
    Standard SIM
    Output video
    None
    Chipset video
    None
    Console Port
    DB9
    Size (Height x Width x Depth)
    30mm x 157mm x 168mm
    Weight
    0.700 kg
    Mains input voltage
    100V to 240V AC
    Power frequency
    50/60Hz, single phase
    Manufacturer's warranty
    1-Year hardware warranty
    Brand
    E-WALL
