Synology DiskStation® DS1522+ NAS Server Toshiba N300 50TB (5x10TB)
    Synology

    Synology DiskStation® DS1522+ NAS Server Toshiba N300 50TB (5x10TB)

    Reference: DS1522+N30050TB
    €1,723.00
    Delivered within 24/48h

    SYNOLOGY DiskStation DS1522+ 8GB 50TB Capacity
    Toshiba N300 disks pre-installed and tested in the workshop. Ready to use!
    NAS 5-Bay Tower
     - Maximum internal capacity 90TB - DDR4 memory 8GB
    4 GbE Ports - 2 eSATA ports - 2 NVMe M.2 2280 SSD Slots - SATA 6Gb/s 2.5" or 3.5" Disk - SSD Support
    Product composition:
    DS1522+ 8GB NAS Tower 5 slots 3,5" and/or 2,5" (3-Year Manufacturer Warranty)
    5 Toshiba N300 10TB drives (3-Year Manufacturer Warranty)

    Quantity
      In stock

    Synology DS1522+

    DiskStation DS1522+

    Versatile data hub for home and office

    Flexible data management for homes and small business

    The 5-bay Synology DiskStation DS1522+ is easy to scale and expand as your needs change, with optional support for up to 15 drives10GbE networking, and NVMe SSD caching. Powered by Synology DiskStation Manager (DSM), it offers a flexible all-in-one solution for data sharing, synchronization, backup, and surveillance.

    CPU

    AMD Ryzen R1600

    2-core 2.6 (base) / 3.1 (turbo) GHz

    Network

    4 x 1GbE LAN ports

    Option 10GBE

    Memory

    8GB DDR4 ECC (32GB max)

    Performance

    Over 736/796 MB/s sequential read/write

    Scalability

    Synology Hybrid RAID, Basic, JBOD, RAID 0, 1, 5, 6 and 10

    Scalability

    Up to 15 hard drives with two DX517 (240TB)

    Versatile Storage for Any Purpose

    The DS1522+ comes out of the box with intuitive and comprehensive file management, media organization, and backup options, making it ideal for IT enthusiasts, creative professionals, and business owners looking for a powerful and compact storage system.
    • Up to 736 MB/s sequential read and 796 MB/s sequential write performance1 enables fast file sharing, syncing, streaming, and backup for multiple users
    • Supports 5 x SATA HDD/SSD 2.5″ and 3.5″ drives, expandable to 15 drives with two Synology DX517 expansion units
    • Up to 32 GB DDR4 ECC memory for protection against potential crashes and inadvertent changes in data through automatic correction of data errors
    • Accommodate multiple streams or transfer tasks with four Gigabit RJ-45 ports, which can be bonded using Link Aggregation to provide automatic network failover and load balancing
    • Maximize return on investment by upgrading your storage platform to meet the most demanding needs with two built-in M.2 NVMe SSD cache slots and an optional 10GbE RJ-45 network upgrade module

    Highlights

    • Dependable Performance
      Up to 736/796 MB/s sequential read/write throughput makes file operations quick and efficient
    • Achieve optimal performance and capacity with SSD caching
      Built-in NVMe M.2 2280 SSD slots promote cache acceleration without taking up storage drive bays.
    • Easily expand storage
      It can accommodate up to fifteen drives to increase storage capacity to meet growing demand.
    • Easily share and sync data
      Access, share and sync your data easily across different operating systems and devices.
    • Fast and stable connectivity
      Four 1GbE ports for easy integration into existing environments with optional 10GbE connectivity2 to handle more specialized, high-bandwidth applications
    • Anytime, Anywhere
      Freely access files on the go and back up photos from your mobile device with iOS and Android™ apps.
    • Virtualization Ready
      Configure and run common virtual machines on your Synology NAS
    • Protect and Restore Data in a Snap
      Back up critical data and reduce your Recovery Time Objective (RTO) with Snapshot Replication.
    • Protect your physical assets with 24/7 monitoring
      Surveillance Station is feature-rich with easy-to-use management tools.

    Cross-platform file sharing

    Synology DS1522+ supports a comprehensive set of network protocols for smooth file sharing experience across Windows, Mac®, and Linux® platforms. Windows AD and LDAP integration allows DS1522+ to fit quickly and easily into any existing environment, without the need to create identical user accounts. Cloud Sync keeps data stored in Dropbox, Google™ Drive, Microsoft OneDrive, Baidu and Box in sync with your personal DiskStation at home. Cloud Station Suite allows you to sync files between multiple devices : Windows PC, Mac, Linux, iOS and Android™ tablets or phones, allowing you to keep everything up to date effortlessly. The DS1522+ combines smooth file sharing capability with enhanced security, even over the Internet and HTTPS, a built-in firewall, and multiple account and multiple IP intrusion auto-blocking mechanisms.

    Everything you need for your home office

    Choose from dozens of applications for small businesses and make the DS1522+ your go-to device for everyday data protection, file management, media sharing, and camera surveillance.

    Synology Home Office
    Synology 10GBe

    Flexible networking options

    Leverage built-in connectivity to integrate the DS1522+ into any network environment, or expand its capabilities by adding plug-and-play modules.

    Failover and network balancing

    Four built-in Gigabit ports with support for automatic network failover and load balancing deliver fast and dependable performance out of the box.

    Easy upgrade to 10GbE

    Add an E10G22-T1-Mini Network Upgrade Module through the easily accessible slot to instantly enable faster networking.

    Synology Extended Warranty

    Designed for Reliability, Backed by Synology

    DS1522+ is designed to reliably store your data and is backed by a three-year hardware warranty from Synology. An optional two-year extended warranty is available in select regions, for up to five years of coverage. Learn more

    The different elements of the DS1522+

    • 1 Status indicator
    • Drive Status Indicators
    • Drive Tray Locks
    • USB 3.2 Gen 1 Port
    • Power Button and Indicator
    • 6 Drive tray
    DS1522+ backpanel
    DS1522+ backpanel
    • Expansion Ports
    • 8 Power Port
    • Network Upgrade Slot
    • 10 USB 3.2 Gen 1 Port
    • 11 1GbE RJ-45 Ports
    • 12 Reset Button
    • 13 System fan
    • 14 Kensington Security Slot
    Western Digital Logo
    Seagate Logo
    Seagate Logo

    Our NAS servers equipped with ready-to-use professional disks!

    Our entire range of NAS servers is equipped with professional hard drives. The disks are installed by our technical teams, the NAS is tested on the network before shipment, to allow faster installation in the company.

    The different discs available:

    • Western Digital WD RED PLUS
    • Western Digital WD PURPLE
    • Seagate IRONWOLF
    • Seagate SKYHAWK
    • Toshiba N300
    • Synology SSD SAT5200 / HDD HAT5300

    Product Details

    Data sheet

    Model
    Synology DiskStation DS1522+
    CPU type
    AMD Ryzen R1600
    Number of CPU sockets
    1
    Number of Cores / Threads
    2C / 2T
    CPU frequency
    2.6 GHz - Burst 3.1 Ghz
    Memory capacity
    8GB
    Memory type
    DDR4 ECC SODIMM
    Number of memory slots
    2 slot
    Maximum memory capacity
    32 GB (16 GB x 2)
    Hardware Encryption Engine (AES-NI)
    Non
    Number of disk bays
    5
    Maximum number of disk bays with extension
    5 + 10 (DX517 x 2)
    M.2 drive slot
    2 (NVMe)
    Compatible disc type
    2.5" SATA SSD
    3.5" SATA HDD
    M.2 2280 NVMe SSD
    Hotswap disk
    Oui
    Installed disk capacity
    50TB
    Disk model installed
    Toshiba N300
    Disk interface
    Serial ATA 6Gb/s (SATA Revision 3)
    Supported RAID type
    JBOD
    RAID 0
    RAID 1
    RAID 5
    RAID 6
    RAID 10
    SHR
    Supported file system
    BTRFS
    EXT3
    EXT4
    FAT
    HFS+
    NTFS
    Number of expansion ports
    2 eSATA ports
    Scalable
    Yes
    PCIe Expansion
    1 x Gen3 x2
    Number of USB Ports
    2 x USB 3.2 Gen 1*
    Number of network ports
    4 x 1GbE (RJ45)
    Size (Height x Width x Depth)
    166 mm x 230 mm x 223 mm
    Weight
    2.7 kg
    Sound level
    22.9 dB(A)
    Mains input voltage
    100V to 240V AC
    Power frequency
    50/60Hz, single phase
    Color
    Black
    White
    Brand
    Synology

    Specific References

    EAN13
    3701446219168
