Product Details
DS420JWDRED16To
Data sheet
- NAS Server
- SYNOLOGY DS420J
- Manufacturer
- Synology
- Processor
- Realtek RTD1296
- Processor Architecture
- 64 bits
- Number of Sockets
- 1
- Processor Speed
- 1.4 GHz
- Number of Cores / Threads
- 4
- Number of memory locations
- 1
- Installed memory capacity
- 1GB (1 x 1 GB)
- Maximum memory capacity
- 1 GB - Total 1 GB
- Memory type
- DDR4
- Disc type
- 2.5" SATA HDD
2.5" SATA SSD
3.5" SATA HDD - Number of eSATA ports
- No
- Number of disk locations
- 4
- Internal maximum storage capacity
- 64 TB
- Installed Storage capacity
- 16TB
- RAID type supported
- Basic
JBOD
RAID 0
RAID 1
RAID 5
RAID 6
RAID 10
Synology Hybrid RAID - Hot swap disk (Hotswap)
- No
- Number of Ethernet interfaces
- 1 x Gigabit Ethernet
- Wake on LAN/WAN
- Yes
- On / Off programmed
- Yes
- Number of USB ports
- 2 x Ports USB 3.0
- Number of maximum IP cameras
- 30 (including 2 free license)
- Packages and Applications
- Antivirus Essential
Applications iOS/Android™
Audio Station
Backup tools
Centre de journaux
Cloud Sync
DNS Server
File Station
Gestionnaire iSCSI
Hyper Backup
Mail Station
Mail Server
Note Station
Photo Station
Serveur FTP
Storage Analyzer
Surveillance Station
Synology Calendar
Synology Chat
Synology Drive
Synology Office
Universal Search
VPN Server
Video Station
Web Station
iTunes® Server - Number of fans
- 2
- Disc models
- Western Digital RED
- Power consumption (Access)
- 21.71 W
- Power consumption (HDD hibernation)
- 7.88 W
- BTU British thermal unit (Hibernation hard drive)
- 26.89 BTU/hr
- Weight (Kg)
- 2,21
- Power supply
- 100V à 240V CA - 50/60 Hz
- Color
- Black
- DLNA Certification
- Yes
- Manufacturer's warranty (Year)
- 2
Remote installation service of a Synology or QNAP NAS server
We offer a remote installation service for your NAS server to get your experience off to a good start with a SYNOLOGY or QNAP NAS server.
This service is declined according to the time* of implementation/training to allow adaptation to your needs :
- Install 60′ :
-
- NAS networking,
- OS initialization,
- Creation of administrator and user accounts,
- Realization of a network share to allow data storage,
- Configuration of 1 client station,
- Overview of backup and creating a backup.
-
- Install 90′ :
-
- NAS networking,
- OS initialization,
- Creation of administrator and user accounts,
- Presentation of the services available and their uses,
- Realization of a network share to allow data storage,
- Configuration of 1 to 2 client stations,
- Overview of backup and creating a backup.
-
- Install 120′ :
-
- NAS networking,
- OS initialization,
- Creation of administrator and user accounts,
- Presentation of the services available and their uses,
- Realization of a network share to allow data storage,
- Configuration of 1 to 2 client stations,
- Publication of services on the Internet,
- Creation of a remote VPN account,
- Overview of backup and creating a backup.
-
*The time indicated is estimated based on a user with some computer knowledge. If the training takes longer, certain actions cannot be carried out. At the end of the allotted time, we will estimate with the customer, the points to be reviewed and the additional time necessary to finalize the installation and the training. This additional time must be acquired through one of the 3 installation packs.
Maintenance service in express exchange of a SYNOLOGY or QNAP NAS
We offer an express D+1 exchange service for your NAS and its disks.
Why offer maintenance when a NAS server is guaranteed by the manufacturer for 2 or 3 years depending on the model ?
The warranty is a return to manufacturer warranty, i.e. you must return the equipment in place to the manufacturer through your supplier. This evaluates the fault and replaces the faulty elements. This operation takes about 15 days with a minimum of 3 to 5 days of return transport. This corresponds to an unavailability of your NAS server for approximately 3 to 4 weeks without any time commitment.
The Express exchange service in 3 categories :
- Express D+1 exchange for the NAS server without disks* in 3-year or 5-year version,
- Express D+1 exchange for the NAS server with Standard disks* (WD Blue/Red/Purple, Seagate Ironwolf/Skyhawk, etc.) in the 3-year or 5-year version,
- Express D+1 exchange for the NAS server with Enterprise* disks (WD Red PRO, Ironwolf PRO, Ultrastar, EXOS, etc.) in the 3-year or 5-year version.
We send by express carrier the NAS box or the failed disk directly to the address provided by the user. A transport voucher allows the return of broken down equipment. In the event that the equipment is not returned within 15 days, this will be invoiced to the user.
*The service must be acquired within a maximum of 3 months following the purchase of the product.
What type of disk to choose for your NAS?
You can find the type of disc according to its use in the following graph:
Remote installation service of a Synology or QNAP NAS server
We offer a remote installation service for your NAS server to get your experience off to a good start with a SYNOLOGY or QNAP NAS server.
This service is declined according to the time* of implementation/training to allow adaptation to your needs :
- Install 60′ :
-
- NAS networking,
- OS initialization,
- Creation of administrator and user accounts,
- Realization of a network share to allow data storage,
- Configuration of 1 client station,
- Overview of backup and creating a backup.
-
- Install 90′ :
-
- NAS networking,
- OS initialization,
- Creation of administrator and user accounts,
- Presentation of the services available and their uses,
- Realization of a network share to allow data storage,
- Configuration of 1 to 2 client stations,
- Overview of backup and creating a backup.
-
- Install 120′ :
-
- NAS networking,
- OS initialization,
- Creation of administrator and user accounts,
- Presentation of the services available and their uses,
- Realization of a network share to allow data storage,
- Configuration of 1 to 2 client stations,
- Publication of services on the Internet,
- Creation of a remote VPN account,
- Overview of backup and creating a backup.
-
*The time indicated is estimated based on a user with some computer knowledge. If the training takes longer, certain actions cannot be carried out. At the end of the allotted time, we will estimate with the customer, the points to be reviewed and the additional time necessary to finalize the installation and the training. This additional time must be acquired through one of the 3 installation packs.
Maintenance service in express exchange of a SYNOLOGY or QNAP NAS
We offer an express D+1 exchange service for your NAS and its disks.
Why offer maintenance when a NAS server is guaranteed by the manufacturer for 2 or 3 years depending on the model ?
The warranty is a return to manufacturer warranty, i.e. you must return the equipment in place to the manufacturer through your supplier. This evaluates the fault and replaces the faulty elements. This operation takes about 15 days with a minimum of 3 to 5 days of return transport. This corresponds to an unavailability of your NAS server for approximately 3 to 4 weeks without any time commitment.
The Express exchange service in 3 categories :
- Express D+1 exchange for the NAS server without disks* in 3-year or 5-year version,
- Express D+1 exchange for the NAS server with Standard disks* (WD Blue/Red/Purple, Seagate Ironwolf/Skyhawk, etc.) in the 3-year or 5-year version,
- Express D+1 exchange for the NAS server with Enterprise* disks (WD Red PRO, Ironwolf PRO, Ultrastar, EXOS, etc.) in the 3-year or 5-year version.
We send by express carrier the NAS box or the failed disk directly to the address provided by the user. A transport voucher allows the return of broken down equipment. In the event that the equipment is not returned within 15 days, this will be invoiced to the user.
*The service must be acquired within a maximum of 3 months following the purchase of the product.
What type of disk to choose for your NAS?
You can find the type of disc according to its use in the following graph:
In the same category
SYNOLOGY DiskStation DS420J 16TB capacity
WD RED drives pre-installed and tested in the workshop. Ready to use!
4-bay NAS Tower - Maximum internal capacity 64 TB - DDR4 memory 1GB
1 GbE port - SATA 6Gb/s 2.5" or 3.5" drive - SSD support
Product composition:
- DS420J NAS Tour 4 slots 3.5" and/or 2.5"
- 4 WD RED 4TB disks
2-year manufacturer's warranty
