Appliance / Firewall Q3x 4 ports Gigabit
pfSense or OPNsense or IPFire appliance
Windows/Linux Mini PC
Appliance IoT / 3CX
4-port gigabit appliance
Celeron 2955U to I7 5500U
L’Appliance Q3x est un boitier Firewall with 4 Gigabit ports, Intel x86 architecture and compatible with all Firewall OSes on the market. You can start the box on a USB key and install …
Compatible OS Firewall:
- pfSense,
- OPNsense,
- Untangle,
- IPFire,
- Sophos,
- Linux iptables,
- …
Compatible OS Microsoft / Linux:
- Windows 10,
- FreeBSD,
- Ubuntu,
- Debian,
- CentOS
- Red Hat,
- …
Compatible OS Router / IoT / Others:
- VyOS,
- 3CX,
- OpenWrt,
- Windows 10 IoT,
- RIOT,
- Contiki NG,
- FreeRTOS
- …
Celeron® 2955U to I7 5500U
2 or 4 core / 2 or 4 Thread
From 1.4 Ghz to 2.4 Ghz burst 3.0Ghz
DDR3L SO-DIMM
2GB / 4GB / 8GB
4 port
GIGABIT RJ45
1 Mini-PCI Express slot
1 Disk / SSD 2.5″
1 SIM + mPCIe slot
Flexible PCIe expansion
HDMI output
Auto-boot Jumper
The Q3x box includes several mPCIe slots to support the installation of a WIFI card or a 4G LTE card and to allow the backup of the main internet link.
HDMI connector to connect a screen.
Carte Intel® HD Graphics / HD 4200 / HD 4400 / HD5500
A jumper on the motherboard allows the box to start automatically. This allows during a power outage to automatically start the Appliance when the power supply is restored. Important for security systems, monitoring, etc.
VESA-compatible
Blank packaging
Power supply
To allow the boxes to be used easily behind a screen, a VESA system is delivered with the screws.
The packaging box is free of any inscription. No identification possible.
The box can be delivered with a power cord for each country:
- EU
- UK
- AU
- US
- CN
Quality internal card equipped :
- 1 x DDR3L-SODIMM 1600Mhz memory slot
- Memory capacity 2GB / 4GB / 8GB Max
- 1 Connector + SATA Power Supply
- 1 x mPCIe slot for SSDs from 16GB to 2 TB,
- 1 x mPCIe slot for WIFI card (Half/Full size)
- or 1 x mPCIe slot for 4G card (Half/Full Size)
- 1x SIM Slot
- 4 x Intel I211-AT Gigabit LAN
- 1 x HD Video (HDMI)
- 1 x RS232 serial port (DB9 Male)
- 1x GPIO connector
- 2 x USB2.0, 2 x USB3.0
- HDD LED, Power LED
- 1 x DC 12V Connector
Environmental characteristics:
- 12V 3A power supply
- DC Jack 5.5mm, 2.5 mm
- Aluminum Alloy Case
- Dimension 187 x 111 x 50 mm
- Packaging 261 x 218 x 75 mm
- Weight 0.95 Kg
- VESA mount
- Kensington Lock bracket
- Cooling Type: Fanless
- Operating temperature: 0°C – 50° Celsius
Product Details
Q3I340416P-EU
Data sheet
- Firewall
- Q3x
- OS Firewall
- pfSense®
- Form factor
- mPCIe Full size
- Processor
- Intel® i3 4005U
- Processor Architecture
- 64 bits
- Number of Sockets
- 1
- Processor Speed
- 1.7 Ghz
- Number of Cores / Threads
- 2
- Number of memory locations
- 1
- Installed memory capacity
- 4GB (1 x 4 GB)
- Memory type
- DDR3L
- Disk Interface
- SATA 6GB/S
- Storage
- Disque SSD 30 Go
- Number of Ethernet interfaces
- 4 x Gigabit Ethernet
- Hardware Encryption
- Yes
- Supported WIFI
- 802.11b/g/n
- Number of USB ports
- 2 x ports USB 3.0 + 2 ports USB 2.0
- Video output
- 1 x HDMI
- Manufacturer's warranty (Year)
- 1
In the same category
E-WALL Appliance Firewall Q3I340 4 ports, installed with pfSense® CE
i3 4005U Dual Core Processor / 4GB / 4 GigE / SSD 16GB / WIFI - EU Power Supply - 1 Year Warranty Return To Workshop
Firewall router under pfSense CE® for TPE / SME up to 50 Users
Installation benefit of pfSense CE® 2.4.x (Community Edition) included, Firewall ready to use.
Intel i3 4005U Dual Core 1.7 Ghz Processor - 4GB RAM - 16GB SSD Storage for OS
SATA SSD disk support and WIFI card support
4 customizable Gigabit ports (WAN / LAN / DMZ / OPT) - AES-NI support
Fanless low consumption case (15W), no noise
Small footprint - EU format power supply
